Venturi Tube 1/2" 3/4" Male Thread Agriculture Fertilizer Injector Automatic Fertilization System Garden Irrigation Supplies

Made of engineering plastic.
Excellent chemical resistance to most of the chemicals.
Highly efficient and compact differential pressure injection device.
Economical and low cost option.
Available in 3/4"or 1/2'' BSP inlet/outlet connection.

A venturi is a device which creates a vacuum when fluid flows through it.
The fluid which creates the vacuum is know as the motive fluid.
The motive fluid for irrigation injectors is the irrigation water itself.
Vacuum created by the venturi sucks fertilizer or chemical into motive water.
Our Venturi are water driven, ie they are driven by the pressure of the main irrigation pipeline.The energy to run these devices reduces the irrigation water pressure of the water line.
Applications: Fertilizer and chemical injection through drip and sprinkler irrigation systems.

Specifications:
Inlet/outlet thread: 3/4 Inch
Material: POM
Flow range: 0.65-2.42 m³/h 0.7-9.5bar
Self-priming capability: 9-92L/h
Inlet/outlet thread: 1/2 Inch
Material: POM
Flow range:0.29-0.81 m³/h 0.7-9.5bar
Self-priming capability: 3-37L/h

Packing include: 1pc

Note:

It is manual measurement, there may be 1-2mm error.

Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you.
